I. Product introduction
     CL6882M02is to satisfy< /span>UPS、EPS< span>, an online battery inspection module designed for systems such as DC power supply and communication power supply. Complete the monitoring and alarm functions of battery pack voltage, battery current, single battery voltage, and battery ambient temperature.
      Applies to 2VThe battery is monitored online.
Second, Main Features
1, Battery voltage measurement: Check the voltage of 54 batteries. And calculate the voltage value of all battery packs.
2. Battery pack current measurement: Collect the signal of the current sensor to calculate the battery pack current. Detect each cell At the same time as the battery voltage, make a battery pack current 3, measure, and record separately.
4. Battery temperature detection: 1 channel ambient temperature signal can be detected.
5. Status indicator: Provide 3 indicators: power, communication, alarm.< br /> 6. Communication function: The host computer uses RS485. The extension uses the CAN communication interface.
7. DIP switch setting: Set the communication protocol and module address through the DIP switch.
8. Parameter setting storage: You can set the module's alarm threshold and other parameter data, set parameters and calibrate through the host computer Data, etc. will be saved in the external EEPROM and will not be lost when power off.
9. Alarm: By setting parameters such as alarm threshold, alarm data can be sent when the battery voltage is abnormal, and The driver alarm refers to the indicator.
